MIKROTIK RB 5009UPr+S+IN
MIKROTIK RB 5009UPr+S+IN
Low stock
-
All orders are dispatched the next business day!
-
We will beat any price. We back all products with a 1 year guarantee.
Order in the next 0 hours 0 minutes to get it by /07/2026
Couldn't load pickup availability
Guaranteed Safe Checkout
Specifications
Details
Product code
RB5009UPr+S+IN
Architecture
ARM 64bit
CPU
88F7040
CPU core count
4
CPU nominal frequency
350-1400 (auto) MHz
Switch chip model
88E6393
RouterOS license
5
Operating System
RouterOS v7
Size of RAM
1 GB
Storage size
1 GB
Storage type
NAND
MTBF
Approximately 200'000 hours at 25C
Tested ambient temperature
-40°C to 60°C
IPsec hardware acceleration
Yes
Powering
Details
Number of DC inputs
3 (PoE-IN, DC jack, 2-pin terminal)
DC jack input Voltage
24-57 V
2-pin terminal input Voltage
24-57 V
Max power consumption
150 W
Max power consumption without attachments
16 W
Cooling type
Passive
PoE in
802.3af/at (ether1), Mode B (ether2-ether8)
PoE in input Voltage
24-57 V
PoE-out
Details
PoE-out ports
Ether1-Ether8
PoE out
802.3af/at
Max out per port output (input 18-30 V)
640 mA
Max out per port output (input 30-57 V)
420 mA
Max total out (A)
2.59 A
Total output current
2.28
Total output power
130
Ethernet
Details
10/100/1000 Ethernet ports
7
Number of 1G Ethernet ports with Reverse PoE (PoE-in)
7
Number of 2.5G Ethernet ports
1
Number of 2.5G Ethernet ports with Reverse PoE (PoE-in)
1
Fiber
Details
SFP+ ports
1
Peripherals
Details
Number of USB ports
1
USB Power Reset
Yes
USB slot type
USB 3.0 type
Max USB current (A)
1.5
Other
Details
CPU temperature monitor
Yes
Current Monitor
Yes
PCB temperature monitor
Yes
Voltage Monitor
Yes
Certification & Approvals
Details
Certification
CE, EAC, ROHS
IP
20
Included parts :
K-55 screw kit
IEC cord
48V2A96W
Connector plug
Description
Description
Specifications
Details
Product code
RB5009UPr+S+IN
Architecture
ARM 64bit
CPU
88F7040
CPU core count
4
CPU nominal frequency
350-1400 (auto) MHz
Switch chip model
88E6393
RouterOS license
5
Operating System
RouterOS v7
Size of RAM
1 GB
Storage size
1 GB
Storage type
NAND
MTBF
Approximately 200'000 hours at 25C
Tested ambient temperature
-40°C to 60°C
IPsec hardware acceleration
Yes
Powering
Details
Number of DC inputs
3 (PoE-IN, DC jack, 2-pin terminal)
DC jack input Voltage
24-57 V
2-pin terminal input Voltage
24-57 V
Max power consumption
150 W
Max power consumption without attachments
16 W
Cooling type
Passive
PoE in
802.3af/at (ether1), Mode B (ether2-ether8)
PoE in input Voltage
24-57 V
PoE-out
Details
PoE-out ports
Ether1-Ether8
PoE out
802.3af/at
Max out per port output (input 18-30 V)
640 mA
Max out per port output (input 30-57 V)
420 mA
Max total out (A)
2.59 A
Total output current
2.28
Total output power
130
Ethernet
Details
10/100/1000 Ethernet ports
7
Number of 1G Ethernet ports with Reverse PoE (PoE-in)
7
Number of 2.5G Ethernet ports
1
Number of 2.5G Ethernet ports with Reverse PoE (PoE-in)
1
Fiber
Details
SFP+ ports
1
Peripherals
Details
Number of USB ports
1
USB Power Reset
Yes
USB slot type
USB 3.0 type
Max USB current (A)
1.5
Other
Details
CPU temperature monitor
Yes
Current Monitor
Yes
PCB temperature monitor
Yes
Voltage Monitor
Yes
Certification & Approvals
Details
Certification
CE, EAC, ROHS
IP
20
Included parts :
K-55 screw kit
IEC cord
48V2A96W
Connector plug
