CUDY WR1500 AX1500 GIGABIT WiFi 6 ROUTER

A Gigabit WiFi 6 router with 4 Gigabit ports, suitable for home internet up to 1000 Mbps, connecting many devices, and reducing latency.

 - 4-Stream Dual-Band Wi-Fi 6

 - 1201 Mbps + 300 Mbps Wi-Fi

 - 4× Gigabit Ethernet Ports

 - Beamforming

 - 60 Connected Devices

 - Covers 100m² (1,100 ft²)

 - Cudy Mesh, VPN Client

 - Cudy App, Cloud Control

Model Version     WR1500 1.0

CPU     CPU Details     1 GHz CPU

Memory/Storage     Flash/ROM     16 MB (128 Mbit) NOR

DDR/RAM     128 MB (1 Gbit) DDR2

Wireless     5 GHz Wi-Fi Speed     1201 Mbps

2.4 GHz Wi-Fi Speed     300 Mbps

5 GHz Wi-Fi Streams     2T2R (2×2 MIMO)

2.4 GHz Wi-Fi Streams     2T2R (2×2 MIMO)

Wi-Fi Antennas     4× Fixed

FEM or PA/LNA

5 GHz: 2× Internal

2.4 GHz: 2× Internal

Beamforming     True

Range Performance     Max: 170 m (558 ft)

Tested in open-space environments with minimal interference. Actual WiFi range may vary depending on layout and wall materials. Refer to the Wall Performance specifications for placement suggestions.

Wall Performance     Two wooden walls with thickness < 10 cm (4'')

One concrete wall with thickness < 20 cm (7'')

Interfaces     Gigabit RJ45 Ports     4

Ethernet Notes     1× WAN port, the rest are LAN ports

LED     System

Physical Buttons

WPS Button

Reset Button

Power Input     DC Jack

Power     Power Methods     DC

DC     12V 1A

Power Adapter     Input: 100 ~ 240 V, 50/60 Hz AC

Output: 12V 1A DC

Max Power Consumption (W)     10W

Reliability     Environment

Operating Temperature: 0 ? ~ 40 ? (32 ? ~104 ?)

Storage Temperature: -40 ? ~ 70 ? (-40 ? ~ 158 ?)

Humidity: 10% ~ 90% non-condensing

Storage Humidity: 5% ~ 95% non-condensing

Certifications     FCC, CE

Mechanical     Installation

Desktop

Wall-mount

Dimension     183.3×109×35 mm

7.22×4.29×1.38 inches

Product Weight

EU: 220 g (7.76 oz.)

ZH: 224.6 g (7.92 oz.)

Package Content

WR1500

Power Adapter

Ethernet Cable

Installation Guide

Ordering Information     Retail Package Weight

EU: 559 g (19.72 oz.)

BR: 549 g (19.37 oz.)

ZH: 519.3 g (18.32 oz.)

Retail Package Dimension     240×230×60 mm

9.45×9.06×2.36 inches

Units per Carton     20

Carton Dimension     49.5×32.5×48 cm

19.49×12.8×18.9 inches

Carton Gross Weight

EU: 12.1 kg (26.68 lbs)

BR: 12.1 kg (26.68 lbs)

ZH: 11.4 kg (25.13 lbs)

Carton Net Weight

EU: 11.2 kg (24.69 lbs)

BR: 11.0 kg (24.25 lbs)

ZH: 10.5 kg (23.15 lbs)

Wireless     Wi-Fi Standards     Wi-Fi 6

Max Wi-Fi Modulation     1024-QAM

Wi-Fi Efficiency     Beamforming

Max Capacity     128

Recommended Client Upper Limit     60

Max Wi-Fi Channel Width     80 MHz

Wi-Fi Security     WPA/WPA2/WPA3

WPS     True

General     Operation Modes

Wi-Fi Router

Access Point

Range Extender

WISP

Client

Mesh     Cudy Mesh

Mesh Backhaul

Wireless Backhaul

Wired Backhaul

Multi-Band Backhaul     True

WAN Mode

DHCP

Static IP

PPPOE

PPTP

L2TP

Internet Failover Sequence

WAN

WISP

Network     QoS     Per-User Rate Limiting

DHCP

Address Reservation

DHCP Client List

Server

IP Versions     IPv4/IPv6

IPv6 Protocols

Relay

Dynamic (SLAAC/DHCPv6)

Static (Fixed IP)

Passthrough

464XLAT

MAP-E

DS-Lite

IPTV/VLAN

Bridge

Tag VLAN

VoIP VLAN

IPTV VLAN

IGMP

IGMP Proxy

IGMP Snooping
